True peak after encoding: three masters measured

This test compares three source masters with decoded lossy versions. It measures changes to true peak and the residual after alignment and level matching; it does not test audibility.

What was measured

Three commercial masters, all 44.1 kHz, 24-bit stereo: a dense pop master and a hip-hop master, both delivered at −0.2 dBTP, and a jazz master delivered at −1.2 dBTP. Each was encoded three ways and decoded back to PCM:

• Ogg Vorbis at 96, 160 and 320 kbps, which are the three bitrates Spotify publishes for its tiers. 96 is the free tier and mobile data, 320 is Very high.
• AAC-LC, 256 kbps, which is what Apple Music publishes.
• Opus, 128 kbps, the commonly reported figure for YouTube music.

Spotify publishes those bitrates. It does not publish which container its apps use, and Ogg Vorbis is the long-reported assumption rather than a documented fact, so everything below is stated as the codec rather than as the platform. If Spotify is serving something else today, the numbers are still what Vorbis at those bitrates does.

Alignment, level matching and the lossless control

The measurement is a null test: subtract the decoded file from the source and look at what is left. Two things have to be right before the subtraction means anything.

Alignment. Encoder delay can affect a null test, so the script uses cross-correlation to align the decoded file with the source before subtraction. In this pipeline, the measured offsets were zero for all three codecs because ffmpeg handled the priming and pre-skip metadata. A control test shifts a signal by known amounts and checks that the aligner recovers those offsets.

Level. A codec can come back a fraction of a decibel off. Uncorrected, that shows up as loss. The script solves for the best-fit gain and reports the correction alongside the residual, so you can see how much of it was level.

The same pipeline first runs a lossless FLAC round trip. It returns a perfect null after decoding, alignment and subtraction. This checks that the pipeline reports identical signals correctly.

True peak after encoding: Ogg Vorbis, AAC-LC and Opus

True peak is read with ffmpeg’s ebur128 filter. The table compares the source reading with each decoded version.

Master	Delivered	Vorbis 96k	Vorbis 160k	Vorbis 320k	AAC-LC 256k	Opus 128k
Pop	−0.2 dBTP	+2.4	+1.7	+0.2	+1.0	+1.7
Hip-hop	−0.2 dBTP	+2.3	+1.6	+0.3	+1.1	+1.5
Jazz	−1.2 dBTP	−0.0	−0.5	−1.0	−0.6	−0.2

For the two masters delivered at −0.2 dBTP, the decoded 96 kbps Vorbis files exceeded +2 dBTP. The 320 kbps versions also exceeded zero, by a smaller amount. The jazz master, delivered at −1.2 dBTP, remained at or below zero in these tests.

These results show why checking codec output can be useful when choosing peak headroom. They do not establish whether an overshoot is audible. That depends on the material, decoder and playback chain.

Residual levels after alignment and level matching

Residual is the level of what is left after subtracting, relative to the source. Lower is closer to the original.

Master	Ogg Vorbis 96k	AAC-LC 256k	Opus 128k
Pop (densest)	−13.3 dB	−22.7 dB	−17.2 dB
Hip-hop	−17.4 dB	−26.3 dB	−20.0 dB
Jazz (most headroom)	−20.0 dB	−31.9 dB	−22.9 dB

Bitrate moves it about as much as material does. On the pop master, Vorbis leaves −13.3 dB at 96 kbps, −18.7 at 160 and −30.2 at 320.

The pop master had the largest residual in each column and the jazz master the smallest. This is a comparison of three files; it does not isolate density as the cause or establish transparency for a codec.

Residuals by frequency band

Broken into bands, against each band's own energy in the source, the three codecs do visibly different jobs on the pop master:

	0–1k	1–6k	6–12k	12–18k	18–22k
Ogg Vorbis 96k	−21 dB	−9 dB	−4 dB	−2 dB	gone
AAC-LC 256k	−26 dB	−21 dB	−13 dB	−11 dB	−12 dB
Opus 128k	−21 dB	−14 dB	−9 dB	−5 dB	gone

At these settings, the Vorbis and Opus results had no retained content in the highest measured band, while AAC did. However, the spectrum alone does not describe all changes: the AAC residual against the pop master was −22.7 dB. Residual level is a signal comparison, not an audibility score.

What this changes about sending a master

If the master is close to full scale, encode and decode a test version and measure it before delivery. In this sample, low-bitrate encodes increased true peak substantially. Whether that produces an audible problem needs a listening test.

Codec previews provide another listening check alongside the lossless master. Soneam includes this option in its review pages. The previews use selected encoders and settings; they do not reproduce every service’s playback chain.

The same measurement, on seventeen records

A later study of seventeen chart tracks compared six encodes, including two AAC implementations at 256 kbps. Their residuals differed by a median of 4.8 dB. That result shows why encoder implementation should be identified alongside codec and bitrate.

The null test script (Python, ffmpeg and numpy)

The script below accepts a WAV and requires ffmpeg, numpy and soundfile. It runs the lossless control before the lossy passes and prints the measurements. Processing takes place on your machine.

Use representative music when applying the test to your own work. If the lossless control does not return a perfect null, investigate that result before interpreting the lossy passes.

"""What a streaming codec actually removes, measured by nulling against the source.

Encoders delay the signal (Vorbis and AAC prime, Opus has a pre-skip), so a naive
subtraction compares a file with a shifted copy of itself and reports noise. This
aligns first, by cross-correlation, then subtracts.

The control matters more than the results: the same pipeline is run on a lossless
round trip, and if that does not come back at around -300 dB the method is broken
and every other number here is decoration.

The codec settings come from projects.audio.CODEC_SPECS, so this measures exactly
what the product plays, not a separate guess about it.

    python scripts/codec_null_test.py master.wav
    python scripts/codec_null_test.py            # generated broadband source

The audio never leaves the machine it runs on, and nothing but numbers comes out:
residual in dB, per-band figures, the true-peak change. Run it where the file
already is. In this repo the dependencies live in the container, so:

    cp master.wav media/
    docker compose exec web uv run --directory /app python \
        /app/src/../scripts/codec_null_test.py /app/media/master.wav

A sine is useless here: a codec has almost nothing to throw away. Use real music,
or the generated source below, which is broadband with transients.
"""

import os
import shutil
import subprocess
import sys
import tempfile

import numpy as np
import soundfile as sf

sys.path.insert(0, os.path.join(os.path.dirname(__file__), '..', 'src'))


def specs():
    try:
        from projects.audio import CODEC_SPECS
        return CODEC_SPECS
    except Exception:
        # Standalone copy for anyone running this outside the repo. Keep in step
        # with projects/audio.py.
        return {
            'spotify': {'encoder': 'libvorbis', 'bitrate': '96k', 'ext': 'ogg',
                        'label': 'Ogg Vorbis 96 kbps'},
            'apple': {'encoder': 'aac', 'bitrate': '256k', 'ext': 'm4a',
                      'label': 'AAC-LC 256 kbps'},
            'youtube': {'encoder': 'libopus', 'bitrate': '128k', 'ext': 'opus',
                        'label': 'Opus 128 kbps'},
        }


def broadband_source(path, seconds=20, sr=44100):
    """Pink-ish noise with transients: something a codec has to make choices about."""
    rng = np.random.default_rng(7)
    n = seconds * sr
    white = rng.standard_normal(n)
    # One-pole cascade gives a rough pink tilt without scipy.
    pink = np.zeros(n)
    b = [0.0, 0.0, 0.0]
    for i in range(n):
        b[0] = 0.99765 * b[0] + white[i] * 0.0990460
        b[1] = 0.96300 * b[1] + white[i] * 0.2965164
        b[2] = 0.57000 * b[2] + white[i] * 1.0526913
        pink[i] = b[0] + b[1] + b[2] + white[i] * 0.1848
    pink /= np.max(np.abs(pink))
    # Transients every half second: what makes a codec's pre-echo audible.
    for t in range(0, seconds * 2):
        i = int(t * sr / 2)
        pink[i:i + 64] += np.hanning(64) * 0.9
    pink = np.clip(pink * 0.5, -1.0, 1.0)
    sf.write(path, np.column_stack([pink, pink]), sr, subtype='PCM_24')
    return path


def run(cmd):
    r = subprocess.run(cmd, capture_output=True, text=True)
    if r.returncode != 0:
        raise RuntimeError((r.stderr or 'ffmpeg failed')[:400])


def to_wav(src, dst, sr):
    run(['ffmpeg', '-y', '-hide_banner', '-loglevel', 'error', '-i', src,
         '-ar', str(sr), '-ac', '2', '-c:a', 'pcm_f32le', dst])


def encode(src, dst, spec):
    cmd = ['ffmpeg', '-y', '-hide_banner', '-loglevel', 'error', '-i', src,
           '-map', '0:a:0', '-c:a', spec['encoder'], '-b:a', spec['bitrate']]
    if spec['encoder'] == 'aac':
        cmd += ['-profile:a', 'aac_low']
    run(cmd + [dst])


def align(ref, test, search=8192):
    """Integer-sample offset that best lines test up with ref.

    Encoder delay is the whole reason this is here: without it the residual is
    the difference between a signal and a shifted copy of itself, which is much
    larger than what the codec did.
    """
    n = min(len(ref), len(test), 400000)
    a = ref[:n] - ref[:n].mean()
    b = test[:n] - test[:n].mean()
    best, best_lag = -1e30, 0
    for lag in range(-search, search + 1, 1):
        if lag >= 0:
            x, y = a[:n - lag], b[lag:n]
        else:
            x, y = a[-lag:n], b[:n + lag]
        if len(x) < 1000:
            continue
        c = float(np.dot(x, y))
        if c > best:
            best, best_lag = c, lag
    return best_lag


def db(x):
    return -np.inf if x <= 0 else 20 * np.log10(x)


def rms(x):
    return float(np.sqrt(np.mean(x ** 2))) if len(x) else 0.0


def true_peak_ebur128(path):
    """True peak from ffmpeg's ebur128, which is a standard implementation and not
    ours. The numbers in the article come from here rather than from the estimate
    below: this is the claim most likely to be argued with, so it should not rest
    on a filter we wrote."""
    r = subprocess.run(
        ['ffmpeg', '-hide_banner', '-nostats', '-i', path,
         '-af', 'ebur128=peak=true', '-f', 'null', '-'],
        capture_output=True, text=True)
    lines = (r.stderr or '').splitlines()
    for i, line in enumerate(lines):
        if 'True peak' in line:
            for nxt in lines[i + 1:i + 4]:
                if 'Peak:' in nxt:
                    try:
                        return float(nxt.split('Peak:')[1].split('dBFS')[0])
                    except ValueError:
                        return None
    return None


def true_peak(x, sr, oversample=4):
    """Fallback: 4x linearly interpolated peak. It under-reads against ebur128 by
    a few tenths, which is the safe direction, and it exists only so the script
    still says something if ebur128 is unavailable."""
    n = len(x)
    up = np.interp(np.linspace(0, n - 1, n * oversample), np.arange(n), x)
    return db(float(np.max(np.abs(up))))


def band_residual(ref, diff, sr, edges=(0, 1000, 6000, 12000, 18000, 22050)):
    """Residual per band, relative to the source's energy in that band.

    The raw residual energy is unreadable: a band that carries most of the music
    will show a big number simply for being loud. What is wanted is how much of
    each band survived, so every figure is against that band's own source energy.
    """
    fr = np.fft.rfft(ref)
    fd = np.fft.rfft(diff)
    freqs = np.fft.rfftfreq(len(ref), 1 / sr)
    out = []
    for lo, hi in zip(edges, edges[1:]):
        m = (freqs >= lo) & (freqs < hi)
        if not m.any():
            continue
        er = float(np.sqrt(np.mean(np.abs(fr[m]) ** 2)))
        ed = float(np.sqrt(np.mean(np.abs(fd[m]) ** 2)))
        out.append(((lo, hi), db(ed / er) if er else -np.inf))
    return out


def measure(src_path, label, spec, tmp):
    ref, sr = sf.read(src_path, always_2d=True, dtype='float64')
    ref = ref[:, 0]

    enc = os.path.join(tmp, 'e.' + spec['ext'])
    dec = os.path.join(tmp, 'd.wav')
    encode(src_path, enc, spec)
    to_wav(enc, dec, sr)
    test, _ = sf.read(dec, always_2d=True, dtype='float64')
    test = test[:, 0]

    lag = align(ref, test)
    if lag >= 0:
        a, b = ref[:len(ref) - lag], test[lag:lag + len(ref) - lag]
    else:
        a, b = ref[-lag:], test[:len(ref) + lag]
    n = min(len(a), len(b))
    a, b = a[:n], b[:n]

    # Level: a codec can come back a hair off, and an uncorrected gain error
    # would show up as codec damage. Report both so nobody has to trust one.
    g = float(np.dot(a, b) / np.dot(b, b)) if np.dot(b, b) else 1.0
    diff_raw = a - b
    diff_gain = a - b * g

    return {
        'label': spec['label'],
        'lag': lag,
        'gain_db': db(abs(g)),
        'residual_db': db(rms(diff_raw) / rms(a)),
        'residual_gain_matched_db': db(rms(diff_gain) / rms(a)),
        'tp_src': true_peak_ebur128(src_path),
        'tp_enc': true_peak_ebur128(dec),
        'tp_src_est': true_peak(a, sr),
        'tp_enc_est': true_peak(b, sr),
        'bands': band_residual(a, diff_gain, sr),
        'bytes': os.path.getsize(enc),
    }


def check_alignment():
    """Shift a signal by a known amount and see whether align() finds it.

    Reporting "+0 samples" for every codec is exactly what a broken aligner looks
    like, so the aligner is asked to prove itself before any codec is measured.
    """
    rng = np.random.default_rng(1)
    x = rng.standard_normal(200000)
    for want in (0, 137, -412, 2048):
        y = np.roll(x, want)
        got = align(x, y, search=4096)
        if got != want:
            sys.exit('alignment is broken: shifted %+d, found %+d' % (want, got))
    return True


def main():
    if not shutil.which('ffmpeg'):
        sys.exit('ffmpeg not found')
    check_alignment()
    tmp = tempfile.mkdtemp()
    src = sys.argv[1] if len(sys.argv) > 1 else broadband_source(
        os.path.join(tmp, 'source.wav'))
    synthetic = len(sys.argv) <= 1
    print('source: %s (%.1f MB)%s\n' % (
        os.path.basename(src), os.path.getsize(src) / 1e6,
        '   [generated: verifies the method, do not publish these figures]'
        if synthetic else ''))

    # The control. If this is not far below everything else, stop reading.
    ctrl = measure(src, 'control', {'encoder': 'flac', 'bitrate': '0',
                                    'ext': 'flac', 'label': 'FLAC (lossless)'}, tmp)
    c = ctrl['residual_gain_matched_db']
    print('%-22s residual %s   <- the method returns "identical" when it should'
          % (ctrl['label'], 'perfect null' if c == -np.inf else '%.1f dB' % c))
    print()

    rows = []
    for key, spec in specs().items():
        r = measure(src, key, spec, tmp)
        rows.append((key, r))
        print('%-22s residual %8.1f dB  (aligned %+d samples, gain %+.2f dB)'
              % (r['label'], r['residual_gain_matched_db'], r['lag'], r['gain_db']))
        if r['tp_src'] is None or r['tp_enc'] is None:
            print('%-22s true peak %+.2f -> %+.2f dB (estimate)   size %.1f MB'
                  % ('', r['tp_src_est'], r['tp_enc_est'], r['bytes'] / 1e6))
        else:
            print('%-22s true peak %+.1f -> %+.1f dBTP (ebur128)   size %.1f MB'
                  % ('', r['tp_src'], r['tp_enc'], r['bytes'] / 1e6))
        parts = []
        for (lo, hi), rel in r['bands']:
            parts.append('%d-%dk %s' % (lo // 1000, hi // 1000,
                                        'gone' if rel > -0.5 else '%.0f dB' % rel))
        print('%-22s %s' % ('', '  '.join(parts)))
        print()

    if synthetic:
        print('The source above is noise with impulses, which is close to the worst\n'
              'case for a perceptual codec: noise is the first thing they discard.\n'
              'Run this on real music before quoting any of it.')
        print()
    if ctrl['residual_gain_matched_db'] > -200 and ctrl['residual_gain_matched_db'] != -np.inf:
        print('WARNING: the lossless control did not null. The numbers above mean '
              'nothing until it does.')


if __name__ == '__main__':
    main()

Frequently asked questions

Does a streaming codec raise true peak?

It did in these examples. The pop master changed from −0.2 dBTP to +2.4 with Vorbis at 96 kbps, +1.7 with Opus at 128 and +1.0 with AAC-LC at 256. The results depend on the source and encoder settings.

Why does a null test need the files aligned first?

Encoders delay the signal. Vorbis and AAC prime, Opus has a pre-skip, and subtracting without correcting for that compares a file with a shifted copy of itself, which reports far more damage than the codec did. The script cross-correlates first. It also matches level, because a codec returning a fifth of a decibel low would otherwise look like loss.

How do you know the measurement is not just measuring itself?

The script checks a lossless round trip through the same alignment and subtraction steps. That control returns a perfect null. It also tests the aligner with known offsets before measuring the encoded files.

Is AAC at 256 kbps transparent?

It was the closest of the three on all three masters, and it was the only one that kept anything above 18 kHz. It still left a residual of −22.7 dB against the densest master. Transparent is a claim about what a listener notices. Subtraction answers a narrower question, and it is the only one measured here.

Why do the three masters give different results?

The three source files differ in arrangement, spectrum, level and processing. The residual was largest for the pop master and smallest for jazz in this sample. The test does not isolate which source characteristic caused the difference.
